Race Sportsman 1.332" OD Conical Springs; 1.900" Installed Height; 16 Springs

• GTIN: 00036584283188
• Brand Name: COMP Cams
• Outer Bottom Spring Outside Diameter: 1.332
• Outer Top Spring Inside Diameter: 0.66
• Outer Top Spring Outside Diameter: 1.06
• Seat Height: 1.9
• Seat Pressure: 145
• Spring Rate: 519
• Valve Spring Series: Race Sportsman
• Amazon ASIN: N/A
• C.A.R.B. Exempt for Racing and Off-Road Only Vehicles?: Yes, but must be a race/competition only vehicle.
• C.A.R.B. Exempt for Federally Certified Vehicles Manufactured Before 1967?: Yes, but must meet tailpipe emission standards for year of vehicle.
• C.A.R.B. Exempt for California Certified Vehicles Manufactured Before 1965?: Yes, but must meet tailpipe emission standards for year of vehicle.
• C.A.R.B. Exempt for Foreign Vehicles Manufactured Before 1967?: Yes, but must meet tailpipe emission standards for year of vehicle.
• C.A.R.B. Exempt for On-Road Vehicles?: Yes
• C.A.R.B. Exemption Reason: No impact on pollution output of vehicle.
• C.A.R.B. E.O. Number: N/A
• Coil Bind Height: 1.175
• Compatible .570" Guide Diameter Spring Seats: 4677-16
• Compatible Retainer: 788-16
• Compatible Shims: 4754
• Damper: No
• Number of Springs: 1
• Outer Bottom Spring Inside Diameter: 0.932

• Country of Origin: United States
• Emissions : CARB Eligible
• Life Cycle Status: Available To Order

• Quantity of Each: 1
• Package UOM: ST
• Dimension: 10.2 x 2.9 x 2.3 inches
• Weight: 3.21 lb
